> 8,400 W/L Best-in-class power density
V4Smart Generation 1 cells set new standards in ultra-high power lithium-ion technology. Their exceptional ability to deliver pulse power up to 400 W for 10 seconds and continuous currents of 100 A makes them ideal for demanding applications in turbo hybrid vehicles, fuel cell trucks, aerospace and defense hybridized systems. Thanks to their low internal resistance, less heat is generated, resulting in a uniform temperature distribution and enabling longer operating time. Alongside an impressive fast-charge capability of under 6 minutes to 80% SOC, Generation 1 Booster cells demonstrate outstanding cycle stability and long lifespan — ensuring reliable performance throughout the entire life.
Key
Features
Ideal heat dissipation and distribution in the cell
> 2,500 cycles at 100% Depth of discharge (DOD) with a capacity of over 80% State of health (SOH)
< 6 minutes fast-charging capability up to 80% State of Charge (SOC)
IATF16949 Automotive standard certified production in series
| Discharge capacity at 0.2C | 2.6 Ah |
|---|---|
| Gravimetric energy density | 140 Wh/kg |
| DCIR at 50% SOC at 25 °C 10A, 10s | < 8 mOhm |
| Volumetric power density (continuous) | > 8,420 W/L |
| Fast charging up to 80% SOC | < 6 min |
| Cycle life at 1C/1C, 25 °C, 80% SOH | > 2,500 cy |
V4Smart sets new standards
Our high-performance Li-ion cylindrical cells define the technology frontier.
Representation based on the cell explorer from the independent cell testing institute, Batemo
Product Datasheet
- V4Smart_Generation 1_V21700 UHP-26_Engineering data sheet Download PDF (317 KB)
